Google Cloud DNS

Overview

Google Cloud DNS is a managed DNS service running on Google's infrastructure. DNS Watchdog connects via a service account to discover zones and sync records.

Authentication

Google Cloud DNS uses Workload Identity Federation to securely connect from AWS without static credentials:

Field	Description
Project ID	Your GCP project ID
Workload Identity Pool Provider	The full provider resource name (e.g. `projects/PROJECT_NUMBER/locations/global/workloadIdentityPools/POOL_ID/providers/PROVIDER_ID`)
Service Account Email	The email of the service account DNS Watchdog will impersonate (e.g. `dnswatchdog@PROJECT_ID.iam.gserviceaccount.com`)

Setup

Grant yourself the required roles

Go to IAM & Admin → IAM in the Google Cloud Console
Click Grant Access and add the following roles to your user:
- Workload Identity Pool Admin (roles/iam.workloadIdentityPoolAdmin)
- Service Account Admin (roles/iam.serviceAccountAdmin)
- Security Admin (roles/iam.securityAdmin)
- Service Usage Admin (roles/serviceusage.serviceUsageAdmin)
- Tag Administrator (roles/resourcemanager.tagAdmin)
- Tag User (roles/resourcemanager.tagUser)
- DNS Administrator (roles/dns.admin)

Enable APIs

Go to APIs & Services → Enabled APIs & Services
Enable the following APIs:
- Identity and Access Management (IAM) API
- IAM Service Account Credentials API
- Cloud DNS API
- Security Token Service API

Create a Workload Identity Pool

Go to IAM & Admin → Workload Identity Federation
Click Create Pool
Set the name to aws-dnswatchdog and display name to DNS Watchdog, then click Continue

Add an AWS provider to the pool

Select AWS as the provider type
Set the provider ID to aws-729428183456 and display name to AWS 729428183456
Enter 729428183456 as the AWS Account ID
Under Attribute Mapping, configure:
- google.subject → assertion.arn
- attribute.aws_account → assertion.account
Click Save

Create a service account

Go to IAM & Admin → Service Accounts
Click Create Service Account
Set the name to dnswatchdog and display name to DNS Watchdog federated SA
Click Create and Continue

Allow the AWS principal to impersonate the service account

On the service account list, click the dnswatchdog service account
Go to the Permissions tab and click Grant Access

In the New principals field, enter:

principalSet://iam.googleapis.com/projects/YOUR_PROJECT_NUMBER/locations/global/workloadIdentityPools/aws-dnswatchdog/attribute.aws_account/729428183456

Add both of these roles:
- Workload Identity User (roles/iam.workloadIdentityUser)
- Service Account Token Creator (roles/iam.serviceAccountTokenCreator)
Click Save

Grant Cloud DNS permissions

Go to IAM & Admin → IAM
Click Grant Access
Enter the service account email (dnswatchdog@YOUR_PROJECT_ID.iam.gserviceaccount.com) as the principal
Assign the DNS Administrator role (roles/dns.admin)
Click Save

Get the provider resource name

Go back to IAM & Admin → Workload Identity Federation
Click the aws-dnswatchdog pool, then the aws-729428183456 provider
Copy the Provider Resource Name — this is the STS audience value

Add the provider in DNS Watchdog

In DNS Watchdog, go to Settings → Providers → Add Provider
Select Google Cloud DNS as the provider type
Enter your Project ID, Workload Identity Pool Provider resource name, and Service Account Email

The Google Cloud DNS credentials form showing the Service Account JSON text area

Choose your access mode (read-only or read-write)
Click Save

# -------- config --------
PROJECT_ID="YOUR_PROJECT_ID_HERE"
ORG_ID="YOUR_ORG_ID_HERE"
PROJECT_NUMBER="YOUR_PROJECT_NUMBER_HERE"

ME="user:you@example.com"
POOL_ID="aws-dnswatchdog"
PROVIDER_ID="aws-729428183456"
AWS_ACCOUNT_ID="729428183456"
SA_NAME="dnswatchdog"
SA_EMAIL="${SA_NAME}@${PROJECT_ID}.iam.gserviceaccount.com"
SA_MEMBER="serviceAccount:${SA_EMAIL}"
ROLE="roles/dns.admin"

# -------- Ensure you've got the roles you need APIs --------
for ROLE in \
roles/iam.workloadIdentityPoolAdmin \
roles/iam.serviceAccountAdmin \
roles/iam.securityAdmin \
roles/serviceusage.serviceUsageAdmin \
roles/resourcemanager.tagAdmin \
roles/resourcemanager.tagUser \
roles/dns.admin
do
gcloud projects add-iam-policy-binding "$PROJECT_ID" \
--member="$ME" \
--role="$ROLE"
done

# -------- enable APIs --------
gcloud config set project "$PROJECT_ID"
gcloud services enable iam.googleapis.com iamcredentials.googleapis.com dns.googleapis.com sts.googleapis.com

# -------- create Workload Identity Pool --------
gcloud iam workload-identity-pools create "$POOL_ID" \
--location="global" \
--display-name="DNS Watchdog"

# -------- create AWS provider (trust AWS account) --------
gcloud iam workload-identity-pools providers create-aws "$PROVIDER_ID" \
--location="global" \
--workload-identity-pool="$POOL_ID" \
--account-id="$AWS_ACCOUNT_ID" \
--display-name="AWS ${AWS_ACCOUNT_ID}"

# -------- create service account --------
gcloud iam service-accounts create "$SA_NAME" \
--display-name="DNS Watchdog federated SA"

# -------- allow AWS account principal to impersonate the SA --------
MEMBER="principalSet://iam.googleapis.com/projects/${PROJECT_NUMBER}/locations/global/workloadIdentityPools/${POOL_ID}/attribute.aws_account/${AWS_ACCOUNT_ID}"

gcloud iam service-accounts add-iam-policy-binding "$SA_EMAIL" \
--role="roles/iam.workloadIdentityUser" \
--member="$MEMBER"

gcloud iam service-accounts add-iam-policy-binding "$SA_EMAIL" \
--role="roles/iam.serviceAccountTokenCreator" \
--member="$MEMBER"

# -------- add attribute mapping --------
gcloud iam workload-identity-pools providers update-aws aws-$AWS_ACCOUNT_ID \
--location=global \
--workload-identity-pool=$POOL_ID \
--project=$PROJECT_ID \
--attribute-mapping="google.subject=assertion.arn,attribute.aws_account=assertion.account"

# -------- grant Cloud DNS permissions  --------
gcloud projects add-iam-policy-binding "$PROJECT_ID" \
--member="serviceAccount:${SA_EMAIL}" \
--role="roles/dns.admin"

# -------- (optional) show the provider resource name (this is the STS audience) --------
gcloud iam workload-identity-pools providers describe "$PROVIDER_ID" \
--location="global" \
--workload-identity-pool="$POOL_ID" \
--format='value(name)'

echo "Project ID:                      $PROJECT_ID"
echo "Workload Identity Pool Provider: projects/$PROJECT_NUMBER/locations/global/workloadIdentityPools/$POOL_ID/providers/$PROVIDER_ID"
echo "Service Account Email:           $SA_EMAIL"

Permissions

Read-only — assign the DNS Reader role (roles/dns.reader)
Read-write — assign the DNS Administrator role (roles/dns.admin)
