Google Cloud DNS

Overview

Google Cloud DNS is a managed DNS service running on Google's infrastructure. DNS Watchdog connects via a service account to discover zones and sync records.

Prerequisites

DNS Watchdog uses Workload Identity Federation to securely connect from AWS without static credentials. You'll need the following values to connect Google Cloud DNS to DNS Watchdog:

Field	Description
Project ID	Your GCP project ID
Workload Identity Pool Provider	The full provider resource name (e.g. `projects/PROJECT_NUMBER/locations/global/workloadIdentityPools/POOL_ID/providers/PROVIDER_ID`)
Service Account Email	The email of the service account DNS Watchdog will impersonate (e.g. `dnswatchdog@PROJECT_ID.iam.gserviceaccount.com`)

The CLI snippets below reuse shell variables (PROJECT_ID, POOL_ID, etc.). If you're using the CLI, set them once at the start of your session:

PROJECT_ID="YOUR_PROJECT_ID_HERE"
PROJECT_NUMBER="YOUR_PROJECT_NUMBER_HERE"
ME="user:you@example.com"
POOL_ID="aws-dnswatchdog"
PROVIDER_ID="aws-729428183456"
AWS_ACCOUNT_ID="729428183456"
SA_NAME="dnswatchdog"
SA_EMAIL="${SA_NAME}@${PROJECT_ID}.iam.gserviceaccount.com"

Granting yourself the required roles

Before you begin, make sure your own user account has the roles needed to create the resources below.

Go to IAM & Admin → IAM in the Google Cloud Console
Click Grant Access and add the following roles to your user:
- Workload Identity Pool Admin (roles/iam.workloadIdentityPoolAdmin)
- Service Account Admin (roles/iam.serviceAccountAdmin)
- Security Admin (roles/iam.securityAdmin)
- Service Usage Admin (roles/serviceusage.serviceUsageAdmin)
- Tag Administrator (roles/resourcemanager.tagAdmin)
- Tag User (roles/resourcemanager.tagUser)
- DNS Administrator (roles/dns.admin)

for ROLE in \
  roles/iam.workloadIdentityPoolAdmin \
  roles/iam.serviceAccountAdmin \
  roles/iam.securityAdmin \
  roles/serviceusage.serviceUsageAdmin \
  roles/resourcemanager.tagAdmin \
  roles/resourcemanager.tagUser \
  roles/dns.admin
do
  gcloud projects add-iam-policy-binding "$PROJECT_ID" \
    --member="$ME" \
    --role="$ROLE"
done

Enabling APIs

Enable the Google Cloud APIs that DNS Watchdog relies on.

Go to APIs & Services → Enabled APIs & Services
Enable the following APIs:
- Identity and Access Management (IAM) API
- IAM Service Account Credentials API
- Cloud DNS API
- Security Token Service API

gcloud config set project "$PROJECT_ID"
gcloud services enable \
  iam.googleapis.com \
  iamcredentials.googleapis.com \
  dns.googleapis.com \
  sts.googleapis.com

Creating a Workload Identity Pool

The pool holds the trust configuration that lets AWS principals authenticate to Google Cloud.

Go to IAM & Admin → Workload Identity Federation
Click Create Pool
Set the name to aws-dnswatchdog and display name to DNS Watchdog, then click Continue

gcloud iam workload-identity-pools create "$POOL_ID" \
  --location="global" \
  --display-name="DNS Watchdog"

Adding an AWS provider to the pool

Add an AWS provider that trusts DNS Watchdog's AWS account and maps its attributes.

Select AWS as the provider type
Set the provider ID to aws-729428183456 and display name to AWS 729428183456
Enter 729428183456 as the AWS Account ID
Under Attribute Mapping, configure:
- google.subject → assertion.arn
- attribute.aws_account → assertion.account
Click Save

# Create the AWS provider (trust the AWS account)
gcloud iam workload-identity-pools providers create-aws "$PROVIDER_ID" \
  --location="global" \
  --workload-identity-pool="$POOL_ID" \
  --account-id="$AWS_ACCOUNT_ID" \
  --display-name="AWS ${AWS_ACCOUNT_ID}"

# Configure attribute mapping
gcloud iam workload-identity-pools providers update-aws "$PROVIDER_ID" \
  --location="global" \
  --workload-identity-pool="$POOL_ID" \
  --project="$PROJECT_ID" \
  --attribute-mapping="google.subject=assertion.arn,attribute.aws_account=assertion.account"

Creating a service account

DNS Watchdog impersonates this service account to manage your DNS zones.

Go to IAM & Admin → Service Accounts
Click Create Service Account
Set the name to dnswatchdog and display name to DNS Watchdog federated SA
Click Create and Continue

gcloud iam service-accounts create "$SA_NAME" \
  --display-name="DNS Watchdog federated SA"

Allowing the AWS principal to impersonate the service account

Grant DNS Watchdog's federated AWS principal permission to impersonate the service account.

On the service account list, click the dnswatchdog service account
Go to the Permissions tab and click Grant Access

In the New principals field, enter:

principalSet://iam.googleapis.com/projects/YOUR_PROJECT_NUMBER/locations/global/workloadIdentityPools/aws-dnswatchdog/attribute.aws_account/729428183456

Add both of these roles:
- Workload Identity User (roles/iam.workloadIdentityUser)
- Service Account Token Creator (roles/iam.serviceAccountTokenCreator)
Click Save

MEMBER="principalSet://iam.googleapis.com/projects/${PROJECT_NUMBER}/locations/global/workloadIdentityPools/${POOL_ID}/attribute.aws_account/${AWS_ACCOUNT_ID}"

gcloud iam service-accounts add-iam-policy-binding "$SA_EMAIL" \
  --role="roles/iam.workloadIdentityUser" \
  --member="$MEMBER"

gcloud iam service-accounts add-iam-policy-binding "$SA_EMAIL" \
  --role="roles/iam.serviceAccountTokenCreator" \
  --member="$MEMBER"

Granting Cloud DNS permissions

Give the service account access to your DNS zones. See Permissions for read-only versus read-write roles.

Go to IAM & Admin → IAM
Click Grant Access
Enter the service account email (dnswatchdog@YOUR_PROJECT_ID.iam.gserviceaccount.com) as the principal
Assign the DNS Administrator role (roles/dns.admin)
Click Save

gcloud projects add-iam-policy-binding "$PROJECT_ID" \
  --member="serviceAccount:${SA_EMAIL}" \
  --role="roles/dns.admin"

Getting the provider resource name

The provider resource name is the value you'll paste into the Workload Identity Pool Provider field in DNS Watchdog.

Go back to IAM & Admin → Workload Identity Federation
Click the aws-dnswatchdog pool, then the aws-729428183456 provider
Copy the Provider Resource Name — this is the STS audience value

gcloud iam workload-identity-pools providers describe "$PROVIDER_ID" \
  --location="global" \
  --workload-identity-pool="$POOL_ID" \
  --format='value(name)'

For convenience, print all three values you'll need in DNS Watchdog:

echo "Project ID:                      $PROJECT_ID"
echo "Workload Identity Pool Provider: projects/$PROJECT_NUMBER/locations/global/workloadIdentityPools/$POOL_ID/providers/$PROVIDER_ID"
echo "Service Account Email:           $SA_EMAIL"

Adding the Provider in DNS Watchdog

Go to Settings → Providers → Add Provider
Select Google Cloud DNS as the provider type
Enter your Project ID, Workload Identity Pool Provider resource name, and Service Account Email

The Google Cloud DNS credentials form showing the Service Account JSON text area

Choose your access mode (read-only or read-write)
Click Save

Permissions

Read-only — assign the DNS Reader role (roles/dns.reader)
Read-write — assign the DNS Administrator role (roles/dns.admin)
